• Transducer: Piezoresistive
• Pressure Range: 3000 to 15000 psia
• Resolution: >0,03 psi
• Temperature error: max. 2 °C
• Temperature Resolution: 0,1 °C
• Temperature Range: 0 - 150 °C
• Memory Capacity: 1.500.000 d.s. available
• Battery Voltage: 1 AA Cell (3,2 to 3,9 Volt)
• Container resistant to H²S

Used to:

• Test wells together with high dynamic pressure or not flowing
• Do PLT production log to define layers contributions, static pressures and Inflow Performance Relationship IPR
• Replace selective swabbing test with plug and packer
• Do multiple extraction conditions tests in order to optimize production design

• Minimize storage constant (C) allowing shorter closing times
• Reduce Gradient change effects and phase rearrangement
